XCMG RP701L Paver

Product Category: Paver
Brand: XCMG
Model: RP701L
Delivery Time: 1-90DAYS
Supply Capacity: 1-500UNITS / Year Waiting for Your Order in Stock
Product Origin: China
After-sales Service: Engineers available to service machinery overseas

Product Feature

XCMG RP701L Asphalt Concrete Paver Machine made in china.

RP601L/RP701L is a tyre type paver featuring good maneuverability, high speed and large traction force. It can meet different paving requirements, and the paving width can be stepless adjusted from 2.5m to 7.0m. It is mainly used for the maintenance of municipal roads, parking lots, highways of high grade and road paving operations. It can be used to pave multiple kinds of materials, especially the asphalt concrete materials, and it can be flexibly used in small, medium or large paving operations. And it also features satisfactory levelness and compactness.

Reliable drive technology

Rear 4WD, large ground contact area, higher traction force than single wheel drive, and the tyre slippery is effectively avoided.

Extra high traction force, applicable to various work conditions, including road construction and site transfer at hilly country.

Advanced screed technology

Hydraulic stepless extension/withdrawal, applicable to the work condition of widened road.

The 3-point suspension system ensures stable extension/withdrawal of screed and good rigidness of the screed.

With stepless adjustable vibrating rotation speed, it can meet different work requirements.

Strong power system

It adopts Shanghai D4114 diesel engine, featuring low temperature start, energy-saving and environmental care.

The large area water radiator and hydraulic oil radiator ensure long time continuous paving operation under 50℃. The hydraulic system is cooled with priority, which ensures high reliability.

Product Parameters

Items	Unit	Parameters
Basic paving width	m	2.5
Max. paving width	m	6.0/7.0
Max. paving thickness	mm	300
Paving speed	m/min	0~18
Travel speed	km/h	0~18
Theoretical Productivity	t/h	400
Hopper Capacity	t	13
Gradeability	%	20
Pavement evenness	mm/3m	3
Transverse levelling accuracy	%	±0.03
Centre crown ratio	%	0~+3
Engine model		D4114ZG2B
Engine power	kw	100
Engine speed	r/min	2400
Fuel tank capacity	L	170
Machine weight	t	15.3~19
Dimension	mm	6096X2580X3832
Auger speed	r/min	0~82
Conveyor speed	m/min	0~36
Vibrator speed	r/min	0~1470
Vibrator amplitude	mm	4
Screed heating		Electrical heating
Auger and conveyor control		Automatic Control by Ultrasonic Sensors
Automatic levelling control		Simulation control
