XE250U Crawler Excavator with 1.2 m³ Bucket

Product Category: Crawler Excavator
Bucket Capacity: 1.4-1.6 m³
Operating weight: 25700 kg
Brand: XCMG
Model: XE250U
Delivery Time: 1-90DAYS
Supply Capacity: 1-500UNITS / Year Waiting for Your Order in Stock
Product Origin: China

Product Feature

The XE250U is equipped with a powerful T4F engine and newly updated valve to deliver high performance you reuqire in tough jobsites. The powerful AC along with ergonomically designed features will make the operator feel comfortable during the work.

Product Parameters

Sales model		Unit	XE250U
Operating weight		Kg	25700
Bucket capacity		m³	1.2
Engine	Model	/	QSB6.7
	No. of cylinders	/	6
	Rated power	kw/rpm	142/2000
	Maximum torque/speed	N.m/rpm	803/1500
	Displacement	L	6.7
Main performance	Travel speed	km/h	6.0/4.1
	Swing speed	r/min	11.6
	Gradeability	°	≤35
	Ground pressure	kPa	56.7
	Bucket digging force	kN	176
	Arm digging force	kN	125
	Maximum tractive force	kN	188.6
Hydraulic system	Rated flow of main pump	L/min	2×260
	Main safety valve pressure	MPa	34.3/37
	Travel system pressure	MPa	34.3
	Swing system pressure	MPa	25
	Pilot system pressure	MPa	3.9
Oil Capacity	Fuel tank capacity	L	400
	Hydraulic tank capacity	L	256
	Engine oil capacity	L	24
Appearance size	A Overall length	mm	10220
	B Overall width	mm	3390
	C Overall height	mm	3180
	D Width of platform	mm	2830
	E Track length	mm	4640
	F Overall width of chassis	mm	3390
	G Track width	mm	800
	H Wheel base of crawler	mm	3842
	I Track gauge	mm	2590
	J Counterweight clearance	mm	1050
	K Min. ground clearance	mm	485
	L Min. tail swing radius	mm	2985
	M Track height	mm	810
Working scope	A Max. digging height	mm	9595
	B Max. dumping height	mm	6745
	C Max. digging depth	mm	6960
	D Maximum depth cut for 2240mm(8 ft) level bottom	mm	6750
	E Max. vertical wall digging depth	mm	5545
	F Max. digging radius	mm	10240
	G Min. swing radius	mm	3510
Standard	Length of boom	mm	6000
	Length of arm	mm	2964
	Bucket capacity	m³	1.2
