Brand New Howo Sinotruck 6x4 Drive Dump Truck For Sale
Product name : Brand New Howo Sinotruck 6x4 Drive Dump Truck For Sale
1 : Horse Power-371
2 : Drive Model-6x4
3 : Payload-35t
4 : Cargo Box Size-5400mmx2500mmx1500mm
5 : Tires-1200R20
Product Specification: Brand New Howo Sinotruck 6x4 Drive Dump Truck
| DUMP TRUCK | |
| Model | 1 |
| Brand | SINOTRUK–HOWO |
| Dimension(L x W x H)(mm) | 8145x2496x3370 |
| Cargo body size (Lx W x H) (mm) | 5400x2300x1300 16 m3 |
| bottom:8mm, side:6mm | |
| Lifting type | Middle Lift |
| Approach/Departure angle(°) | 19/26 |
| Overhang(front/rear) (mm) | 1500/1739 |
| Wheel base (mm) | 3825+1350 |
| Max speed(km/h) | 75 |
| Curb weight(kg) | 12290 |
| Loading Weight(kg) | 30000 |
| Fuel tanker capacity(L) | 300 |
| Fuel consumption(L/km) | 20-40 L/100 km |
| Clutch | Single-plate dry clutch Φ430mm |
| Fuel type | Diesel |
| Horse Power | 336HP |
| Emission | EURO II |
| Engine | WD615.69, water-cooled,four strokes,6 cylinders in line with water cooling, turbocharged and intercooling, directly injection |
| Transmission | HW19710,10 forwards and 2 reverse |
| Service brake | Dual circuit compressed air brake |
| Parking brake | Spring energy, compressed air operating on rear wheels |
| Auxiliary brake | Egine exhaust brake |
| Model | 8118 hydraulic steering with power assistance |
| HF9 , Steering with double T-cross section beam | |
| HC16, Pressed axle housing, central double reduction with differential locks between axles and wheels | |
| Optional | |
| Tire | 12.00R20 |
| Cab | Right Hand Driving |
| Battery | 2X12V/165Ah |
| Alternator | 28V-1500kw |
| Starter | 7.5Kw/24V |
JINAN CHASING VEHICLE CO., LTD was established in 2004. It is a company inte-grating product research and development, production, trade, and mainly engaged in the manufacture of semi trailers, trailers, trailer accessories, and used truck sales.
The company covers an area of 150,000 square meters. It is a designated special vehicle manufacturer approved by the Ministry of Industry and Information Technology of China. It is also one of the earliest domestic companies to obtain China's well-known trademarks, ISO, CCC, and compulsory product certification.
